Konica KM HS1000 Printhead
$1,551.00 - 1,599.00/pc
Konica KM HS1000 Printhead
Description:
The Konica Minolta KM HS1000 printhead is a piezo on-demand printhead featuring an all-nozzle Independent drive system with a multi-line structure. In contrast with the existing 3-cycle system drive, an independent drive system that enables simultaneous emission from all 1024 nozzles has been adopted. The high-density structure featuring 4 lines of 256 nozzles aligned with high precision enhances positioning accuracy to realize high-definition print quality.
This printhead can be used as a replacement of the Konica Minolta KM1024i LHE.
We recommend to change the head cables when installing a new printhead.
Printer Compatibility:
Agfa Anapurna (100, H2500i LED, M2050i, M2500i, M3200i )
Allwin (S320UV, S500UV, UVT 2030, UVT 2512, UVT+ 2030, UVT+ 2512)
Docan H1000
Flora HJ 5000UV
Human Digital Technology M-JET
IIJ ColourPrint-72
JHF Vista (R3300, R6000, V300UV, V500UV)
Optimum Digital KR Hybrid UV
Skyjet (FT2512i, FT3020i)
Taimes T50UV
Yicong YD2512-KD
Flora (PP 2512UV, XTRA 330)
Specifications:
• Technology: Piezo Drop On-Demand
• Native resolution: 360npi (90npi x 4lines)
• Cal. Droplet Size: 30 pico litre
• Grayscale maximum drop count: 8 drops
• Total nozzles: 1024 (256nozzles x 4lines)
• Print width: 72 mm
• Firing Frequency: 27 Khz
• Drive Voltage: 13+-3V
• Ink compatibility: UV (White)
• Dimensions: W131 mm x D17 mm x H94 mm
• Weight: 150g
Attention:
1. The printhead is required to be installed by professional persons.
2. Due to the nature of Printer Parts and the many factors that go into installing them, we do not accept returns or give refunds on electronic or service parts. Once the package is delivered, it is the customer’s responsibility to check the package for damage.
3. Please seriously pay attention on information of printhead model while purchasing from us. Once received your item, please inspect if the printhead matches up with the model you required.If you have any problems, it is very important that contact us as soon as possible before installing it onto machine. Please be aware that we don’t accept any return and refund once the printhead is installed on the machine.
